     Notices

This product does not included CT:s

For sampling voltage ＞480Vac PT connection is required

APRILICE

     Product description

The Sigen Sensor TPX-CH is designed for C&I energy management systems, working with SigenStor system networking to monitor grid-side power data and support accurate system control, energy management, and coordinated operation, while supporting 3P4W and 3P3W wiring scenarios for flexible configuration according to different site requirements.

Sigen Sensor TPX-DH does not included CT:s, which needs to be purchased separately with the following requirements: Primary rated current In/A ≥ Measuring current, secondary rated current I0/A is 5A or 1A, accuracy ≥ 0.5, and the default CT ratio of the power sensor is 200, need to be reset according to the CT ratio.

For sampling voltage ≤480Vac, direct voltage sampling is supported; for sampling voltage ＞480Vac, PT connection is required. CT and PT are purchased separately and the CT/PT ratios can be set based on the actual project configuration.
